Gotion GRID 20MWh (available in Q2 2026)
Gotion GRID 20MWh
World's First 20MWh PV Storage with 25-Year Lifespan
- I-driven O&M boosts efficiency by 50%
- Ultimate protection with seven safety layers
- Air–liquid cooling cuts annual energy use by 20%
- Full-area enclosure, IP55 & C5 rated
- Compact layout saves 38% of land
Product strengths
Cost reduction & optimization
- Ultra-large single-cabinet design delivers higher energy density.
- Air–liquid cooling trims annual energy consumption by 20%.
- Optimized ESS layout reduces land use by 38%.
Extended lifespan
- Full lifecycle optimization design.
- 25-year design lifespan.
Ultimate safety
- Seven-layer protection plus IP55 / C5 certification.
- Reliable operation in extreme environments.
Smart operation
- Multilingual intelligent control platform improves O&M efficiency.
- Modular integration solution shortens construction cycles.
Technical specifications
| Model | Gotion GRID 20MWh | ||
|---|---|---|---|
| Electrical parameters | |||
| Cell capacity | LFP-314Ah | ||
| Nominal energy | 20.06 MWh | ||
| Nominal Voltage | 1331.2 V | ||
| Environmental parameters | |||
| Operating temperature | -30°C ~ 55°C | ||
| Altitude rating | ≤ 3000 m | ||
| Structural parameters | |||
| Ingress protection rating (IP Rating) | IP55 | ||
| Cooling method | Liquid-Cooling | ||
| Fire suppression system |
• Pack-level immersion suppression
• Total-flooding gas extinguishing • Water spray protection |
||
| EU/US Compliance | IEC 61000*, IEC 62477-1, UL 1973*, UL 9540* (*Certification in progress) | ||
| Dimensions (W*D*H) | 5000 * 10000 * 4600 mm | ||
| Weight | ≈ 170 t | ||
